At Shenyang Emt Piping Technology Co., Ltd., we specialize in advanced chemical quill systems designed for precise fluid sampling in industrial environments. Our chemical quills represent the pinnacle of engineering excellence, providing reliable and accurate sample extraction from process pipelines without compromising system integrity.

Chemical quills, often referred to as sampling quills, are specialized tubular devices inserted into process pipelines to obtain representative fluid samples for analysis and quality control. Unlike simple injection devices, our chemical quills are engineered with precision to maintain process conditions while enabling safe and efficient sampling operations.

1. Technical Specifications and Design Features

Our chemical quill systems incorporate several critical design elements that ensure optimal performance:

Material Composition:

• 316/316L stainless steel construction
• Hastelloy C-276 options for corrosive applications
• Alloy 20 variants for sulfuric acid environments
• Titanium grades for chloride-containing services

Pressure and Temperature Ratings:

• Maximum working pressure: 1500 PSI (103 bar)
• Temperature range: -50°C to 400°C
• Vacuum service capability
• Thermal cycling resistance

Dimensional Specifications:

• Standard insertion lengths: 6-48 inches
• Outer diameters: 1/4″ to 1″ NPT connections
• Custom lengths available upon request
• Precision-machined tip configurations

2. Applications Across Industries

Our chemical quill solutions serve diverse industrial sectors with specific sampling requirements:

Petrochemical Industry:

• Crude oil sampling for quality assessment
• Refinery process stream monitoring
• Additive injection verification
• Product quality certification

Chemical Processing:



• Reactor feed and effluent sampling
• Catalyst performance monitoring
• Intermediate product quality control
• Waste stream analysis

Power Generation:

• Boiler feedwater chemistry monitoring
• Cooling water treatment verification
• Steam quality assessment
• Emissions compliance sampling

Pharmaceutical Manufacturing:

• Process intermediate sampling
• Quality assurance testing
• Batch consistency verification
• Regulatory compliance documentation

3. Technical Advantages and Innovations



Our chemical quill systems incorporate several innovative features:

Advanced Flow Dynamics:

• Optimized tip designs for representative sampling
• Reduced turbulence and mixing effects
• Minimized pressure drop across the quill
• Enhanced sample integrity preservation

Safety Enhancements:

• Double-contained systems for hazardous materials
• Emergency isolation capabilities
• Leak detection integration
• Pressure relief mechanisms

Customization Options:

• Material selection for specific corrosion resistance
• Length and diameter variations
• Connection type alternatives
• Special coating applications
